Shunhao Factory; Automatic and high speed melamine tableware machine manufacturer
Brand:
ShunhaoPayment:
LC, TTProduct Origin:
ChinaColor:
GreenShipping Port:
XiamenMachine Features
1. Utilizing a programmable logic controller (PLC) system for efficient control.
2. Utilizing robust steel material for the machine body, ensuring durability and longevity.
3. Incorporating top-notch components from renowned brands for optimal performance.
4. Extensive expertise in providing technical assistance to international clients.
5. Achieving precision molding and consistently delivering high-quality, high-yield products.
Technical Parameters
No. |
Content |
DTB 200 |
1 |
Main Cylinder Nominal Pressure |
200Tons |
2 |
Maximum Working Pressure |
210kg/cm2 |
3 |
Main Cylinder Piston Diameter |
Ø370mm |
4 |
Main Cylinder Working Stroke |
560mm |
5 |
Adjustable Table Distance |
500~960mm |
6 |
Heating Plate Size |
680*620mm/720*720mm |
7 |
Tension Column (Heat Treatment Grinding) |
Ø100*2200mm |
8 |
Machine Size(length * width * height) |
2.0*1.42*2.7 M |
9 |
Machine Weight |
4800KGS |
■ PS: Specifications subject to change without notice.
Application of Melamine Tableware Compression Molding Machine
Innovative Solution for Crafting Crockery
Introducing a cutting-edge range of plate compression molding machines designed specifically for melamine products. These state-of-the-art machines are perfect for creating various shapes of melamine tableware, trays, sinks cup surfaces, chop, and more. With the ability to apply appliques and perform hot stamping, this series of machines offers unparalleled versatility in the field crockery manufacturing.
